seawater applications (cooling with seawater, shipboard piping,
offshore platform piping and heat exchangers), in the chlorine
manufacturing industry, in the pulp and paper industry, in the
refinery industry and in the production of the precursor
chemicals that go into everyday products, such as plastic soft
drink bottles.
Many in the chemical process industry are becoming more
aware that titanium and zirconium metals are quite cost
effective, readily available and easily welded with the proper
fabrication techniques. Cost effectiveness needs to take in not
only the initial cost of the equipment but also the cost of
maintenance over the life of the unit and the cost of
production lost due to corrosion failures and downtime due to
excessive maintenance. Since both titanium and zirconium
equipment used in nitric acid production have shown extended
life for the components (over 25 years life with minimal
maintenance), their cost effectiveness can be shown to be
exceptional.
Titanium and zirconium can be dependably welded by
welders trained in the correct methods used with these metals.
Not every fabricator can manufacture a high-quality ASME Code
vessel or heat exchanger out of reactive metals; but there are
fabricators in the US and around the world who are
knowledgeable and experienced with this type of work. The key
to getting reliable, corrosion-resistant reactive metal equipment
is to only contract with reputable fabricators who have
experience working with and welding reactive metals.
Figures 1 and 2 show a cooler-condenser that was fabricated
out of grade 2 titanium (the standard grade used in most
chemical industry applications) and another cooler-condenser
that was fabricated out of zirconium because the anticipated
concentrations and temperatures for this plant’s process were
much higher. Both of these were designed and built to customer
specifications and ASME Code, and are still in service today.
UAN production
This is the final step in the production of nitrogen-based
fertilizers – where the urea and the nitric acid is combined with
ammonium nitrate to produce urea ammonium nitrate (UAN).
Again, as in the production of the urea, there are no excessively
corrosive conditions in this stage. Most of the equipment used
here is, again, fabricated out of carbon steel or austenitic
stainless steel (304L or 316L).
Conclusion
Reactive metals (titanium and zirconium) are successfully used in
the production of nitrogen-based fertilizers. This is only in the
area of the plant where the nitric acid is produced, where
excellent corrosion resistance to oxidising, high-temperature
conditions are common. Titanium and zirconium have been
successfully used for years throughout the entire chemical
process industry to eliminate or minimise corrosion within the
chemical process. These reactive metals (or corrosion resistant
alloys [CRAs] as some would call them) can be successfully used
to manufacture the highest quality chemical process equipment
by experienced fabricators. The use of titanium and zirconium in
fertilizer production plants can be considered a success in that it
works to reduce the cost of production and minimises
maintenance costs and downtime due to unanticipated
corrosion problems.
