installed are used to eliminate lumpy material. Then three
stainless steel elevators, each with a capacity of 120 t,
transport the product to quarto bagging lines where a
duplex weighing system was installed. Stainless steel air
exhausting filters are located on top of these bagging lines
and a unique air dryer system is used. The bags are then
closed with a four needle sewing system. The product is
then transported to a truck/container offloading conveyor
system. This line has a weighing belt conveyor to check the
product flow and a unique blending scroll auger to coat
the fertilizer before bagging.
The factory is operated from a central control room,
where complete factory visualisation is possible on two
20 in. computer flat screens. The line is fully controlled by
a PLC and PC. All bagging lines are connected to this
central control system so that the operator can control
the factory from this room. All generated data is stored.
In this machine set up, six lines are placed next to each
other, with a total capacity of 300 tph. Two robots are
installed in the existing lines, with the possibility of adding
another four robots at a later stage, meaning a total of six
robots can be installed. Using robot arms for the heavy work
creates a safe working environment for Yara’s employees.
Outlook
As a supplier of blending, bagging and transport equipment
for the fertilizer industry, EMT is constantly improving its
machines and plans to work as efficiently as possible when
developing new technologies. In the future, EMT expects
to extend its network and delivery worldwide.
Figure 4.
A five hopper Weighcont continuous blender
line, which adds micronutrients, and a bagging line for
50 kg bags, installed in Rwanda.
Figure 3.
A five hopper Weighcont blender line and
bagging line installed for ATA in Ethiopia, with a central
capacity of 50 tph.
Doyle Enterprises
6831 County Road 334, Palmyra, Mo, 63461
Doyle, Quincy, IL. USA. Tel. +1(217) 222-1592
Doyle, Palmyra, MO Tel. +1(573) 300-4009
Small Bag Portable Container
* In two 10 foot/3 meter containers.
* Capacity 45 ton per hour.
* 900 bags of 25 or 50 kg per hour.
Weighcont Blender
* Capacity of 20 to 200 ton per hour.
* Custom built.
* Unlimited number of hoppers.
* Computer controlled.
Shamrock Blender
* Capacity of 25 to 70 ton/m³ per hour.
* Machine size 4,5-5,4-7-9-11,5-14 ton.
* Easy and gentle blending process.
* Blending and weighing are separated.
EMT
Molenpad 10, 1756 EE ‘t Zand
The Nederlands.
Tel.+31 (0) 224 591213
email:
-
High Speed Bagging Line
* For big bags - jumbo bags.
* Capacity 50 to 70 ton m³ per hour.
* 120 kg to 1250 kg bags.
* Suitable for granular and powder materials.
* Available with dust reducing system.
The Doyle and EMT Alliance
Can provide you with all the Blending, Bagging
and Transport equipment you need.
